GEOSYNTHETICS

connection clips. TechSlope Mesh facing systems have several
advantages over conventional rigid facings like shotcrete. SPotLiGHt

Major advantages of TechSlope Mesh include:
• High tensile strength
• Light weight
• Exceptional corrosion resistance with Galfan coating
• Economical
• Green solution

TechAnchor Self Drilling Anchors

Techrhombus High Tensile rope Net System
TechAnchors are high performance self-drilling anchors with high
tensile strength, excellent bond with soil and rock and exceptional
durability. TechAnchors are available in various sizes and with
protective coatings like zinc, epoxy etc. The anchors are supplied
with all required accessories like drill bits, couplers, bearing plate
and hex nuts. Several types of drill bits like cross, clay, jetting,
segment etc. are available to suit different site conditions.
TechAnchor system is fully compliant to En 14490.
TechAnchors are designed to drill without casing in loose soils
as well as rock. These have extensive applications in slope
stabilization, retaining structures, foundations of structures,
tunnelling and mining. The system can be used for both
temporary and permanent applications.
TechRhombus is a very strong, tough and flexible steel rope net With TechAnchors, there is no need for cased boreholes and there
system comprising high tensile steel wire ropes (1960 n/mm2) is increased productivity since drilling, insertion and grouting is
and steel wire knot (SWK) or high resistance clip (HRC) jointing done in a single operation.
systems which can be used for both active and passive rock fall
protection. TechRhombus with Galfan/Galvanized coating has
exceptional corrosion resistance.
In the simple drapery system for rock fall protection, TechRhombus
is used as the primary mesh and a layer of double twisted
hexagonal steel wire mesh is used as the secondary mesh. Both
meshes are secured with top layer of anchors/rock bolts and top
support rope secured with wire rope anchors.

TechSlope Mesh Flexible Slope Stabilization System
TechSlope Mesh is a very strong and flexible net made from high
tensile steel wires which is used as a flexible facing system for TFI Solution near the approach road adjacent to bio-diversity park
stabilizing rock and soil slopes in combination with rock bolts / @ TSIIC Cyberabad in the state of Telangana
anchors / soil nails. The mesh is connected to anchoring elements
using steel bearing plates or using a grid beam method. The For more details contact :
product with Galfan coating has exceptional corrosion resistance. Email: info@techfabindia.com
Adjacent TechSlope Mesh panels are connected using special Website: www.techfabindia.com
