TICKER TAPE
EQUIPMENT Case Maxxum 145 Sandvik Mobile Crushers and Screens has launched its new
CASE RELEASES DETAILS OF 2022 TRACTORS
SANDVIK LAUNCHES THIRD GENERATION IMPACT
CRUSHER
CVXDrive loader
3-Series equipment line, starting with the release of the third
Case has released details
covering changes to its
tractor ranges for the 2022
The third-generation Q1353 is a mid-sized tracked machine that
has been designed for the recycling and contractor sectors.
model year. generation QI353 impact crusher.
The standard wheelbase Sandvik QI353 mobile impact crusher
Case IH Puma 140-175 tractors are now available with power It can process up to 400 t of material an hour and includes PRISEC
outputs ranging from 155 to 200 hp. Variants using the CVXDrive crushing technology, which enables it to be used of both primary
have had a series of transmission upgrades to improve the shuttle and secondary applications.
and acceleration/deceleration behaviour, achieved through Sandvik said: “Its feed arrangement includes a new feed hopper
newly-enhanced pedal sensitivity. with curved heavy-duty sides for greater capacity and tapered
As with the Puma range, the six-cylinder Maxxum tractors also feed arrangement to reduce blockages and ensure continuous
feature improved acceleration/deceleration response and pedal crushing. It also features a new pan feeder with geared drive and
sensitivity. The tractors offer power ranging from 115 to 150 hp, a larger pre-screen with improved access to replace media.”
delivered via a ‘clever’ CVT system. This top power figure is a five At the core of the QI353 is a new mid-size Prisec impact crusher,
horsepower gain over the four-cylinder Maxxum 145. which boasts the largest feed opening 1,170 x 730 mm (46 x 29
The Case IH Farmall C range now has four variants, featuring in) and largest rotor diameter 1,150 mm (45 in) within its class,
power outputs from 90 to 117 hp. All tractors use the new Stage for higher capacity & greater energy efficiency,” said the
5-compliant, four-cylinder 3.6 L engine from FPT. This has a larger manufacturer. Adjustable apron curtains and tip speed ensure
displacement and four valves per cylinder to deliver up to 10% a wide range of product gradations can be achieved. Also, all
more torque at lower engine speeds (1,300 rpm). plant conveyors have larger discharge heights for increased
The 3.6 L engines use the new FPT HI-eSCR2 exhaust treatment stockpiling capacity. According to Sandvik, the mobile machine
system, which integrates a diesel oxidation catalyst, a is “particularly useful for contractors who change jobs frequently”
maintenance-free particulate filter and a selective catalyst and has been designed for easy operator use. It features an
reduction unit. Even with the addition of this hardware, engine automated control system that incorporates the manufacturer’s
size has been maintained to support ground clearance and new Optik interface. Optik comprises a colour display that
manoeuvrability. integrates troubleshooting, diagnostic and support capabilities,
The Farmall C tractors also feature the Active Drive 2 transmission, as well as the My Fleet telematics system.
with powershuttle and powerclutch. This has 24 gears (forward and Unlike the manufacturer’s second generation models, the 3-Series
reverse), and optional cruise control and creep speeds. There QI353 has been equipped with a new access platform located
are also front and rear axle electro-hydraulic differential locks, under the feeder and pre-screen, and a three-sided 270-degree
electronic draft control, a 64-litre/min hydraulic pump, three- service and maintenance platform. The 3-Series model is available
speed PTO and optional front linkage. with optional belt scales for tph (tonnes per hour) monitoring of
fines and stockpile conveyors. Fitted to the machine’s conveyor,
HIAB LAUNCHES NEW SUPER HEAVY LOADER CRANE the scales allow productivity data to be displayed on the main
Hiab, part of Cargotec, has user interface. The QI353 also comes factory ready to accept
launched a new 110 tonne metre Sandvik’s new HS323 hanging screen module, which enables
super heavy loader crane, the operators to use the crusher in an open or closed circuit. Sandvik
HIAB iQ.1188 HiPro. said: “The HS323 enhancements include; prepared to accept belt
The crane comes with the scales for tph monitoring on fines and stockpile conveyor belts,
company’s new control system subframe enhanced for improved screen media access and
SPACEevo tensioning and an updated mid-size stockpile conveyor.”
The crane comes with the “The unique design enables set-up in less than 30 minutes and
company’s new control system SPACEevo and its CombiDrive 4 can be fitted without the use of additional lifting equipment.
remote control, which it says delivers new productivity and safety It added: “The patent pending hanging screen option delivers
benefits. The HIAB iQ. 1188 HiPro is the largest Hiab crane to date multi-functionality as a one, two or three-way split screener, as well
with a long reach and high lifting capacity, but still lightweight in as a highly productive and efficient impact crusher.”
a compact package, the company says. It is similar in size to a
90 tonne metre range model. The company says this means it
can be installed easily on 4 axle vehicles and still leaves room
for payload, as well as reducing costs and fuel consumption. The
performance to weight ratio is achieved by the new V12-Power
boom profiles. The HIAB iQ.1188 HiPro is the first in the iQ. range that
will set a new standard for precise manoeuvres and high speeds,
and personalised settings to improve productivity.
